Incoloy 945 Rod High Temperature Strength Corrosion Resistance For Harsh Environments

Name: Incoloy 945 Rod High Temperature Strength Corrosion Resistance For Harsh Environments
Brand: NikTech
Price: 1 USD

Brand Name : NikTech

Model Number : Incoloy 945

Certification : ISO 9001:2008

Place of Origin : China

MOQ : 150kgs

Price : Negotiatable

Payment Terms : L/C,T/T,Western Union,MoneyGram

Supply Ability : 300 Ton per Month

Delivery Time : 2-30days

Packaging Details : Wood box

Tensile Modulus : 195 GPa

Shear Modulus : 74 GPa

Powder Or Not : Not Powder

Poisson's Ratio : 0.31

Melting Range : 2317-2510 F

Testing Facility : Accept third party testing such as SGS

Thermal conductivity : 10.9 W/m-K

Price Term : Ex-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU

Coefficient of Expansion : 14.19 µm/m C

Equal Grades : alloy 945

Tensile Strength : 1194 MPa

Yield trength : 920 MPa

Type : UNS N09945

Surface Treatment : Anodized,Brushed,Mill Finished,Polished

Specific Heat : 445 J/kg C

Elongation : 27.8%

Reduction of Area : 48.0%

Impact Strength : 76ft•lb

Contact Now

Incoloy 945 Rod: High-Temperature Strength and Corrosion Resistance for Harsh Environments

Incoloy 945 Rod (UNS N19945) is a high-performance alloy that provides outstanding resistance to corrosive environments and high-temperature strength. Known for its impressive mechanical properties, Incoloy 945 is widely used in industries where severe conditions, such as high temperatures and corrosive chemicals, are common. The alloy is a unique combination of nickel, iron, and chromium, with additional elements like molybdenum, copper, and titanium, making it ideal for use in chemical processing, power generation, and marine applications.

The superior resistance of Incoloy 945 to oxidation and sulfidation at elevated temperatures, along with its excellent stress-corrosion cracking resistance, makes it a preferred material for harsh operating environments. This alloy is capable of withstanding extreme conditions while maintaining high strength and durability over long periods.

Chemical Composition

Element	Composition (%)
Nickel (Ni)	45.0 – 50.0
Chromium (Cr)	19.5-23.0
Iron (Fe)	Balance
Molybdenum (Mo)	3.0 – 4.0
Niobium(Nb)	2.5 – 4.5
Copper (Cu)	1.5 – 3.0
Titanium (Ti)	0.5 – 2.5
Aluminum (Al)	0.01 – 0.7
Manganese (Mn)	1 max
Silicon (Si)	0.5 max
Carbon (C)	0.005 – 0.004
Sulfur (S)	0.03 max
Phosphorous(P)	0.03 max

Mechanical Properties

Property	Value
Tensile Strength	1030 MPa (150 KSI)
Yield Strength (0.2% Offset)	825 MPa (120 KSI)
Elongation	15% min
Hardness	30–40 HRC
Thermal Conductivity	10.9W/m•ºC

Physical Properties

Property	Value
Density	8.2g/cm³
Melting Range	1270-1377 °C
Electrical Resistivity	1.10 mW•m
Permeability at 200 oersteds (15.9 kA/m)	1.003

Standards and Specifications

UNS: N19945
ASTM: B423, B424
NACE: MR0175 / ISO 15156
ISO: 15156, 2007

Applications

Incoloy 945 Rod is commonly used in:

Chemical Processing: Ideal for equipment exposed to high temperatures and aggressive chemicals, such as reactors, piping systems, and heat exchangers.
Power Generation: Used in gas turbines, steam turbines, and other high-temperature components.
Marine Engineering: Perfect for components exposed to seawater, offering excellent resistance to chloride stress corrosion.
Oil and Gas: Suitable for applications in harsh environments like oil extraction and refining, especially where high sulfur content is involved.

Frequently Asked Questions (FAQ)

Q1: What is the primary advantage of Incoloy 945?
A1: Incoloy 945 offers excellent resistance to high-temperature corrosion and stress-corrosion cracking, making it suitable for extreme industrial applications in corrosive and high-temperature environments.

Q2: Can Incoloy 945 be welded?
A2: Yes, Incoloy 945 can be welded using conventional techniques such as TIG and MIG welding. However, preheating and post-weld heat treatments are often required to minimize the risk of cracking.

Q3: What are the ideal applications for Incoloy 945 Rod?
A3: Incoloy 945 Rod is typically used in chemical processing, power generation, marine engineering, and oil & gas industries, where high strength and corrosion resistance are critical.
